BNET FO JOINT CLOSURE IP68 UPTO 24F HORIZONTAL INLINE TYPE WITH ALL ACCESSORIES

General Information

 BNET this series fiber optic splice closure is a kind of multi-purpose optical cable connection product, which can connect and divide optical fiber. The connector box has 8 inlet and outlet ports.

Can be applied to a variety of optical cable (loose sleeve, skeleton, ribbon, etc.), and can be installed in a variety of environments (overhead, bracket, pipe, hand hole, manhole), and for a variety of connecting methods (distribution, bridge, division, etc.).

Feature

·       Mechanical seal: Excellent sealing performance, reusable.

·       Protection grade is IP 68. Entry port:4 ports(2 in 2 out)

·     It applies to any sort of cables (loose tube, skeleton, ribbon etc.) and is available for usage of various connections (distribute, bridging, divergence etc.) in multiple environments (aerial, bracket, pipe- lined, handhole, manhole.) Size of package: 475×200×140mm (1 set)

·       It adopts mixture of vulcanized silicon rubber and non-vulcanized self-adhesive rubber for seal.

·     Inner suspension fixation insures cable to test requirements of cable torque, stretching, pressure, bending.

·      Small in size, simple in structure, easy in operation.

 Specification

Item	Parameter
Dimension	280×180×85
Weight	1.8-2.2
Cable entrance ports	8
Splice tray	1or2
Splice capacity	24
IP level	IP68
Operation temperature	-40~+60℃
Relative humidity
Atmospheric pressure	70~106Kpa
