BNET FIBER MM 1X6 G50/125 OM4 INDOOR/OUTDOOR DIELECTRIC FR-LSZH LOOSE TUBE CABLE 1500N MADE IN GREECE

CABLE DESCRIPTION – APPLICATIONS

Central loose tube, indoor / outdoor, fully dielectric FO cables suitable for air-blown installation in plastic cable ducts, laying on open or protected trenches or cable trays. They are protected against longitudinal moisture penetration through dry, swellable elements. The layer of glass yarns used as strain relief elements provide extra tensile strength, dielectric protection against rodents and prevent peripheral penetration of water. The flame retardant, low smoke - halogen free (FR LSZH) outer sheath makes them suitable for installation inside buildings or elsewhere that special precautions against fires must be taken. These cables are specially designed for fast and low-cost fiber optic deployment in urban (metropolitan) or local telecommunication networks

BASIC CHARACTERISTICS OF OPTICAL FIBERS (6 CORE)
The cables can be ordered with all available categories of single mode and / or multimode optical fibers. MULTI-MODE OPTICAL FIBERS (typical values)
Parameter	Graded index 50/125 OM4
Core diameter	50 ± 2.5
Cladding diameter	125.0 ± 1.0 mm
Coating diameter (non-colored)	245 ± 10 mm
Core concentricity error	£ 1.5 mm
Cladding non-circularity	£ 1.0 %
Attenuation coefficient at 850 nm	£ 2.5* dB/km
Attenuation coefficient at 1300 nm	£ 0.6* dB/km
Bandwidth at 850 nm	3500 / 4700 Mhz. km
Bandwidth at 1300 nm	500 / 500 Mhz. km
Numerical Aperture	0.200±0.015

 The price is per meter.
